川消中低压消防泵产品应用范围以及特点
来源：http://www.cx-fire.com/ 日期：2022-07-08
中低压消防泵可完全替代普通低压泵。它可以独立输出低压水流、中压水流和软管水流，也可以同时输出低压水流、中压水流和软管水流，以便消防车在时间进行灭火。同时近距离。，还可以远距离供水，也可以向高层供水，火灾现场的机动性大大增强。那么我们来说说中低压消防泵产品的应用范围和特点。
The medium and low pressure fire pump can completely replace the ordinary low pressure pump. It can output low-pressure water flow, medium pressure water flow and hose water flow independently, and can also output low-pressure water flow, medium pressure water flow and hose water flow at the same time, so that the fire truck can extinguish the fire at the first time. At the same time, close., It can also supply water from a long distance or to high-rise buildings, which greatly enhances the mobility of the fire scene. Then let's talk about the application scope and characteristics of medium and low pressure fire pump products.
中低压消防泵产品适用范围：
Application scope of medium and low pressure fire pump products:
用于输送不含固体颗粒的清水和物理化学性质与水相似的液体。主要用于消火栓、喷淋林、稳压器等。输送液体流量范围0.42~333L/s，压力范围0.8~2.25mpa，配套功率范围0.18~160KW，口径范围为15mm~400mm
It is used to transport clean water without solid particles and liquids with physical and chemical properties similar to water. It is mainly used for fire hydrants, sprinkler forests, regulators, etc. The conveying liquid flow range is 0.42~333l/s, the pressure range is 0.8~2.25mpa, the supporting power range is 0.18~160kw, and the caliber range is 15mm~400mm
中低压消防泵产品特点
Features of medium and low pressure fire pump
1、结构紧凑、体积小、外形美观。其立式/卧式结构决定了安装面积小，其与泵脚中心重合，从而提高了泵的运行稳定性和使用寿命。
1. Compact structure, small volume and beautiful appearance. Its vertical / horizontal structure determines that the installation area is small, and its center of gravity coincides with the center of the pump foot, thereby improving the operation stability and service life of the pump.
2、运转平稳、噪音低、部件同心度高。
2. Stable operation, low noise and high concentricity of components.
3、采用的水力模型，效率高，性能优良。
3. Advanced hydraulic model is adopted, with high efficiency and excellent performance.
4、轴封采用机械密封，具有耐磨、无泄漏、使用寿命长的特点。
4. The shaft seal adopts high-quality mechanical seal, which has the characteristics of wear resistance, no leakage and long service life.
5、泵的进出口在同一水平轴上，通径规格相同，便于管路连接，装卸极为方便。
5. The inlet and outlet of the pump are on the same horizontal shaft, with the same diameter specification, which is convenient for pipeline connection and loading and unloading.
6、维修方便，无需拆卸管路，只需拆下泵盖螺母，取出电机及传动部件即可进行维修。
6. It is convenient to maintain. There is no need to remove the pipeline. Just remove the pump cover nut and take out the motor and transmission parts for maintenance.
Chuanxiao explains the meaning of the fire pump model
XBD3.2/5-65L-160A
XBD3.2/5-65L-160A
XBD-消防泵组代号
XBD code of fire pump set
3.2-设计压力（1/10MPa）表示扬程为32m
3.2-design pressure (1/10mpa) means the lift is 32m
5-设计流程（L/S）
5-design process (l/s)
65-进出口直径（mm）
65 inlet and outlet diameter (mm)
L型结构是垂直的
L-shaped structure is vertical
160-叶轮公称直径（mm）
160 nominal diameter of impeller (mm)
A-叶轮切割
A-impeller cutting
