①灭火剂瓶组及驱动气体瓶组框架

① Fire extinguishing agent bottle group and driving gas bottle group frame

1、按设计要求，安装灭火剂及驱动气体瓶组架；

1. According to the design requirements, install the fire extinguishing agent and drive gas bottle assembly frame;

2、瓶组架牢固固定在地面上，必须打地脚螺栓，各连接部件安装牢固防止震动和移位。

2. The bottle assembly frame is firmly fixed on the ground, foundation bolts must be installed, and all connecting parts must be installed firmly to prevent vibration and displacement.

3、应留有足够的操作空间，使操作面距墙或两操作面之间的距离不宜小于1m。

3. Enough operating space shall be reserved to ensure that the distance between the operating surface and the wall or between the two operating surfaces should not be less than 1m.

②灭火剂瓶组

② Fire extinguishing agent bottle group

1、将灭火剂瓶组与称重装置连接，悬挂于瓶组框架上，其安装高度与方向应一致；

1. Connect the fire extinguishing agent bottle group with the weighing device, hang it on the bottle group frame, and its installation height and direction should be consistent;

2、瓶组上手动操作手柄应朝向操作面；

2. The manual operation handle on the bottle group should face the operation surface;

3、对瓶组进行编号

3. Number the bottle group

4、误喷射防护帽出厂时配装，以避免瓶组在转运期间各种原因导致的误喷放造成事故，因此瓶组未联接管路前或维修检查需断开管路时应安装该防护帽，拆下的防护帽应注意保存和保管。

4. The accidental spraying protective cap is assembled when leaving the factory to avoid safety accidents caused by accidental spraying caused by various reasons during the transportation of the bottle group. Therefore, the protective cap should be installed before the bottle group is not connected to the pipeline or when the pipeline needs to be disconnected for maintenance and inspection, and the removed protective cap should be preserved and kept.

③驱动气体瓶组

③ Drive gas cylinder group

1、瓶组固定在瓶组架上，固定牢固；

1. The bottle group is fixed firmly on the bottle group frame;

2、电气连接线应沿瓶组架或墙面固定，防止其他物体碰撞；

2. The electrical connection line should be fixed along the bottle rack or the wall to prevent other objects from colliding;

3、气体驱动管路布置应横平竖直，采用支架固定；

3. The gas drive pipeline shall be arranged horizontally and vertically, and fixed with supports;

4、低泄高封阀必须垂直地面向上安装；

4. The low discharge and high seal valve must be installed vertically upward;

5、气体驱动管路安装完毕，应进密性能试验，试验压力为6.0MPa,压力保持5min不泄漏；

5. After the installation of the gas drive pipeline, the air tightness test should be carried out. The test pressure is 6.0MPa, and the pressure should be maintained for 5min without leakage;

6、误喷射防护帽出厂时配装，以防止瓶组在转运期间各种原因导致误启动容器阀造成事故，因此瓶组未联接管路前或维修检查需断开管路时应安装该防护帽，拆下的防护帽应注意保存和保管。

6. The protective cap for mistakenly spraying is assembled when leaving the factory to prevent safety accidents caused by mistakenly starting the container valve due to various reasons during the transportation of the bottle group. Therefore, the protective cap should be installed before the bottle group is not connected to the pipeline or when the pipeline needs to be disconnected for maintenance and inspection, and the removed protective cap should be preserved and kept.

7、安装完毕，驱动气体瓶组正面应标明对应防护区名称或编号。

7. After installation, the name or number of the corresponding protection zone shall be marked on the front of the drive gas cylinder group.

④电磁型驱动装置

④ Electromagnetic drive

为确保，防止误喷，电磁型驱动装置应在系统验收合格之后安装，拔出保险销方能正常使用。

In order to ensure safety and prevent accidental spraying, the electromagnetic drive device should be installed after the system passes the acceptance, and can be used normally only after the safety pin is pulled out.

⑤集流管及连接管

⑤ Collecting pipe and connecting pipe

1、集流管安装在灭火剂瓶组框架上，调整位置后固定牢靠；

1. The collecting pipe is installed on the frame of the fire extinguishing agent bottle group, and fixed firmly after adjusting the position;

2、带泄放装置的集流管，泄压口不应朝向操作面、走道和门等，以免泄压时对人员造成伤害。

2. For the collecting pipe with safety relief device, the pressure relief port should not face the operating surface, walkway, door, etc., so as to avoid injury to personnel during pressure relief.

⑥选择阀安装

⑥ Selector valve installation

1、安装高度不宜超过1.7m，其手动操作杆应朝向操作面；

1. The installation height should not exceed 1.7m, and its manual operating lever should face the operating surface;

2、安装完毕，在操作杆附近标明防护区名称或编号的性标志。

2. After installation, a permanent sign with the name or number of the protection area shall be marked near the operating rod.

⑦喷嘴安装

⑦ Nozzle installation

1、外露部分应美观，连接螺纹不应露出吊顶；

1. The exposed part shall be beautiful, and the connecting thread shall not expose the ceiling;

2、川消小编认为在安装时应逐个核对型号、规格和喷洒方向，严格按设计要求。

2. Chuanxiao Xiaobian believes that the model, specification and spraying direction should be checked one by one during installation, and the design requirements should be strictly followed.
