泡沫钩管是一种移动式泡沫灭火设备，用于生产和喷射空气泡沫，扑救没有固定泡沫灭火装置的地下，半地下和小型油罐的油类和汽油火灾。下面川消小编为您讲解泡沫钩管的组成与使用。

Foam hook pipe is a mobile foam fire extinguishing equipment, which is used to produce and spray air foam to put out oil and gasoline fires in underground, semi underground and small oil tanks without fixed foam fire extinguishing devices. Next, Chuanxiao will explain the composition and safe use of foam hook pipe.

泡沫钩管的组成

Composition of foam hook pipe

泡沫钩管组成是由钩管和空气泡沫产生器两部分构成。钩管上部有弯形喷管，用以钩住着火的油罐上，并向罐内喷射泡沫，而下端为空气泡沫产生器，装有65毫米管牙接扣，用水带连接，输送空气泡沫混合液。当泡沫混合液混合经过多孔锥管逐渐扩散，形成良好的空气泡沫，从弯形喷管喷出，扑救火灾，操作简单方便。

The foam hook tube is composed of hook tube and air foam generator. The upper part of the hook pipe is equipped with a curved nozzle to hook the burning oil tank and spray foam into the tank, while the lower end is an air foam generator, which is equipped with a 65mm pipe thread connector and connected with a water belt to transport air foam mixture. When the foam mixture is mixed and diffused gradually through the porous cone tube, a good air foam is formed, which is ejected from the curved nozzle to put out the fire. The operation is simple and convenient.

泡沫钩管的使用

Safe use of foam hook pipe

在使用本产品时，应具备泡沫消防车或装有空气泡沫混合器的消防泵。

When using this product, it should be equipped with a foam fire truck or a fire pump equipped with an air foam mixer.

1.当油罐失火时，用水带接通消防泵与空气泡沫钩管。

1. When the oil tank is on fire, the water hose is connected to the fire pump and the air foam hook pipe.

2.扑救高度超过5米的油罐火灾时，应将空气泡沫管栓装在拉梯上，并将其升高，使喷口超过灌口高度后，紧靠罐壁;扑救地下或半地下油罐火灾时，应将空气泡沫钩管移近油罐放在便于钩挂的地方。

2. When putting out a fire in an oil tank with a height of more than 5m, the air foam pipe should be bolted on the ladder and raised so that the nozzle is close to the tank wall after exceeding the height of the nozzle; When fighting underground or semi underground oil tank fires, move the air foam hook pipe close to the oil tank and place it at a place convenient for hook.

3.待消防泵正常供水后，讲水压调整到空气泡沫钩管的工作压力5公斤/厘米2 (也可以在3-5公斤/厘米2压力范围使用，但混合量和空气泡沫量相应变化。

3. After the fire pump supplies water normally, adjust the hydraulic pressure to the working pressure of air foam hook pipe 5 kg/cm2 (it can also be used within the pressure range of 3-5 kg/cm2, but the mixing amount and air foam amount change accordingly.

4.开启控制空气泡沫产生器进水和吸液管路得阀门。

4. Open the valve that controls the water inlet and suction pipeline of the air foam generator.

5.将空气泡沫混合器的调节阀指针拨在“16” 位置的泡沫混合液量示数.上。

5. Turn the pointer of the regulating valve of the air foam mixer to the foam mixture volume indicator at the "16" position.

6.待弯型喷管正常喷射泡沫后，将空气泡沫钩管在油罐_上。

6. After the curved nozzle sprays foam normally, hook the air foam pipe to the oil tank_ On.

7.本产品对于3%型和6%型的普通空气泡沫液和氟蛋白泡沫均适用。

7. This product is applicable to 3% and 6% ordinary air foam liquid and fluoroprotein foam.
