　　大家好，今天我给大家介绍一下我们这个消火栓箱验收的一个知识点有哪些？

　　Hello everyone, today I will introduce to you a knowledge point about the acceptance of our fire hydrant box?

　　首先第一个就是我们这个消火栓，它应该安装在我们远离门轴侧，这一侧应该安装在这一侧。它离我们这个边侧的距离应该是多少呢？14公分。

　　The first one is our fire hydrant, which should be installed on the side away from the door shaft, and this side should be installed on this side. What is the distance it should be from our side? 14 centimeters.

　　然后它的高度是多少？高度的话是1.1米，是从我们消火栓中心开始算算到我们建筑完成面的标高是1.1米。好，

　　And what is its height? In terms of height, it is 1.1 meters, calculated from the center of our fire hydrant to the finished elevation of our building, which is 1.1 meters. Okay, okay,

　　下面一个还有就是我们这个门的一个开启的一个角度，角度是不小于120度。

　　The next one is the opening angle of our door, which is not less than 120 degrees.

　　里边这个消防水带的话，它的长度是不宜超过25米。

　　The length of this fire hose inside should not exceed 25 meters.

　　然后这个地方还要做一个消防软管，消防软管的话它的长。它的直径不小于19。

　　And then this place also needs to make a fire hose, which is longer. Its diameter is not less than 19.

　　而这个地方还要配置我们的消防水枪。好背板，

　　And this place also needs to be equipped with our fire water guns. Good backboard,

　　包括这个消火栓离我们背板的这个距离。他不应该小于十公分。好，

　　Including the distance between this fire hydrant and our backboard. He should not be less than ten centimeters. Okay, okay,

　　这大概是我们验收的一些知识点，这些知识点的话是根据什么来的，是根据我们这个消防给水以及消火栓系统技术规范 G b50974杠2014。

　　These are probably some of the knowledge points we have accepted. What are these knowledge points based on? They are based on our technical specification G b50974 for fire water supply and hydrant systems, 2014.
