什么是消防软管卷盘？根据现行标准《消防软管卷盘》（GB15090-2005），消防软管卷盘由阀门、输入管道、卷盘、软管和喷枪等组成，在灭火过程中可以快速展开软管喷射灭火剂的灭火装置。

What is a fire hose reel? According to the current national standard fire hose reel (gb15090-2005), the fire hose reel is composed of valve, input pipe, reel, hose and spray gun. In the process of fire extinguishing, the fire extinguishing device of hose spraying fire extinguishing agent can be quickly deployed.

消防软管卷盘的型号编制应符合下列规定，例：灭火剂为水，额定工作压力0.8MPa，软管内径19mm，软管长度25m。软管卷盘，型号为：JPS0.8-19/25。

The model compilation of fire hose reel shall comply with the following provisions, for example: the fire extinguishing agent is water, the rated working pressure is 0.8MPa, the inner diameter of hose is 19mm, and the length of hose is 25m. Hose reel, model: jps0 8-19/25。

设定范围

Set range

1、下列建筑物或场所，不得设置室内消火栓系统，但应设置消防软管卷盘或手提式消防水带：

1. Indoor fire hydrant system shall not be set in the following buildings or places, but fire hose reel or portable fire hose shall be set:

1）单层、多层的D、E级车间（仓库），耐火等级为一、二级及以下可燃物。

1) Single layer and multi-layer D and E-class workshops (warehouses), with fire resistance rating of class I, II and below combustibles.

2)耐火等级三、四级，建筑体积不超过3000m?的D类厂房；防火等级为三、四级，建筑体积不超过5000m?的E类车间（仓库）。

2) The fire resistance rating is grade III and IV, and the building volume does not exceed 3000m? Class D plant; The fire rating is grade III and IV, and the building volume does not exceed 5000m? Class E workshop (warehouse).

3）粮仓、金库、远离城镇、无人看管的独立建筑。

3) Granaries, vaults, independent buildings far from towns and unattended.

4)建筑物与水接触会引起燃烧和爆炸。

4) Buildings in contact with water can cause combustion and explosion.

5）室内无生产和生活供水管道，室外消防用水取自蓄水池等建筑容积不超过5000m?的建筑物。

5) There are no production and domestic water supply pipelines indoors, and the outdoor fire water is taken from reservoirs and other buildings with a volume of no more than 5000m? Buildings.

2.人口密集的公共建筑、建筑高度大于100m的建筑物、建筑面积大于200㎡的商业服务网点，应安装消防软管卷盘或便携式消防水带。

2. Fire hose reels or portable fire hoses shall be installed in densely populated public buildings, buildings with a building height of more than 100m and commercial service outlets with a building area of more than 200 m2.

3、高层住宅室内应配备手提式消防水带。

3. Portable fire hose shall be equipped in the room of high-rise residence.

4、养老设施内应安装直接与室内供水系统相连的消防软管卷盘，消防软管卷盘之间的距离不应大于30.0m。

4. Fire hose reels directly connected to the indoor water supply system shall be installed in the elderly care facilities, and the distance between fire hose reels shall not be greater than 30.0m.

5、DN65的消火栓应在步行街两侧商铺外每隔30m设置一次，并应配备消防软管卷盘或消防水带。店铺应设置自动喷水灭火系统和火灾自动报警系统，每个走廊应设置自动喷水灭火系统。

5. DN65 fire hydrant shall be set every 30m outside the shops on both sides of the pedestrian street, and shall be equipped with fire hose reel or fire hose. The shop shall be equipped with automatic sprinkler system and automatic fire alarm system, and each corridor shall be equipped with automatic sprinkler system.

设置要求

Setting requirements

1、可与室内消火栓同箱安装。

1. It can be installed in the same box as the indoor fire hydrant.

2、消防软管卷盘应配备内径不小于ф19的消防水带，其长度宜为30.0m；手提式水带应配备公称直径为25的内衬消防水带，长度为30.0m。

2. The fire hose reel shall be equipped with an inner diameter of not less than ф 19. The length of fire hose should be 30.0m; Portable hose shall be equipped with lined fire hose with nominal diameter of 25 and length of 30.0m.

3、消防软管卷盘和手提水带应配备等效喷嘴直径为6mm的消防水枪。

3. Fire hose reel and portable hose shall be equipped with fire water gun with equivalent nozzle diameter of 6mm.
