川消电控消防水炮需要进行消防联动
来源：http://www.cx-fire.com/ 日期：2022-07-12
智能消防水炮成为大空间建筑的主要防火，灭火中坚力量；而另一重要的类别电控消防水炮，应用的场景不一样，流量的大小不一样，安装的高度与智能消防水炮也不同，那么电控消防水炮需要不需要进行消防联动呢？
Intelligent fire water cannon has become the main fire prevention and extinguishing backbone of large space buildings; Another important category is the electric fire water monitor. The application scenarios are different, the flow is different, and the installation height is different from that of the intelligent fire water monitor. Does the electric fire water monitor need fire linkage?
电控消防水炮的喷射介质是水，需要的额定压力是0.8MPa，有压力，免不了要使用消防水泵，使用消防水泵，就牵扯到如何启动水泵，如果说在使用电控消防水炮前，先把水泵启动起来，等到水炮用完，再去停止水泵，这种方式就直接成为***的手动了。所以电控消防水炮也需要联动，在进行定位后，开启电动阀的同时，消防水泵应该能够自动联动。
The injection medium of the electrically controlled fire water monitor is water, and the required rated pressure is 0.8MPa. If there is pressure, it is inevitable to use the fire water pump. Using the fire water pump involves how to start the water pump. If you start the water pump before using the electrically controlled fire water monitor, wait until the water monitor runs out, and then stop the water pump, this method will directly become * * * s manual. Therefore, the electric fire water monitor also needs linkage. After positioning, the fire water pump should be able to automatically linkage while opening the electric valve.
How is the linkage of Chuanxiao electric fire water monitor?
一、电控消防水炮具有五种控制方式，而需要喷水灭火就要打开电动阀，电动阀的控制方式在现场控制箱，或者遥控器，只需要将联动信号连接在电动阀上信号端子就可以完成联动。
1、 The electric fire monitor has five control modes, and the electric valve needs to be opened if it needs to spray water to extinguish the fire. The control mode of the electric valve is in the field control box or the remote controller. The linkage can be completed only by connecting the linkage signal to the signal terminal on the electric valve.
二、现场控制箱和遥控器的按键上面都有启动水泵和停止水泵的按键，这个是怎么样运行的呢，在水炮上有输出的信号端子，可以直接连接到消防水泵，实现现场控制箱和遥控器同时启动水泵后，再打开电动阀，保证水炮充足的供水压力。
2、 There are buttons to start and stop the water pump on the buttons of the on-site control box and the remote controller. How does this work? There is an output signal terminal on the water monitor, which can be directly connected to the fire pump. After the on-site control box and the remote controller start the water pump at the same time, open the electric valve to ensure that the water monitor has sufficient water supply pressure.
电控消防水炮需要联动消防水泵，而且超过150米遥控方式更简单方便，远距离只需要遥控水炮的炮口对准火焰，开阀就可以了，甚不用对准，直接开阀将水柱移动，更具有视觉震撼力；同时手动开启雾状，在一定情况下，效果会更好，比较经常需要降温的地方，使用雾状范围大，降温效果更好。
The electrically controlled fire water monitor needs to be linked to the fire pump, and the remote control method is more simple and convenient for more than 150 meters. For a long distance, it only needs to aim the muzzle of the remote control water monitor at the flame, open the valve, or even do not aim. Directly open the valve to move the water column, which is more visually shocking; At the same time, manually turn on the fog, and the effect will be better under certain circumstances. Where it is often necessary to cool down, the use of fog has a wide range and better cooling effect.
The above is all about the problems and precautions introduced to you today. I hope it can help you. If you want to know more, you can contact us by phone or follow our website http://www.cx-fire.com , our staff will contact you in time.
