七氟丙烷灭火系统按是否有管网分类讲述

来源:http://www.cx-fire.com/ 日期:2022-07-19

七氟丙烷灭火系统是一种常用的气体灭火系统。可根据现场、保护区大小、客户需求设计不同类型的灭火类型。有哪些类型的七氟丙烷灭火系统?七氟丙烷灭火系统按有无管网可分为管网灭火系统、无管网灭火系统和特种灭火系统。
Heptafluoropropane fire extinguishing system is a commonly used gas fire extinguishing system. Different types of fire extinguishing can be designed according to the site, the size of the protected area and the needs of customers. What types of heptafluoropropane fire extinguishing systems are available? Heptafluoropropane fire extinguishing system can be divided into pipe network fire extinguishing system, pipe network fire extinguishing system and special fire extinguishing system according to whether there is pipe network.
管网七氟丙烷灭火系统
Heptafluoropropane fire extinguishing system of pipe network
定义:灭火剂从贮存装置经主管支管输送到喷淋部件进行喷淋的灭火系统。管网灭火系统分为单元独立系统和组合分配系统两大类。
Definition: a fire extinguishing system in which the extinguishing agent is transported from the storage device to the spraying parts through the main and branch pipes for spraying. Pipe network fire extinguishing systems can be divided into unit independent systems and combined distribution systems.
1、单元独立系统是只保护一个保护区,没有选择阀的系统,每个保护区独立对应一套气体灭火剂储存装置。
1. The unit independent system is a system that only protects one protected area without selector valve, and each protected area independently corresponds to a set of gas extinguishing agent storage device.
2、组合分配系统是两个或多个保护区,通过选择阀的选择和分配,共用一套气体灭火剂储存装置(按大保护区的数量计算)。这种方法可以大大节省工程成本。
2. The combined distribution system is two or more protected areas, which share a set of gas extinguishing agent storage devices (calculated according to the number of large protected areas) through the selection and distribution of selector valves. This method can greatly save the engineering cost.
当任一保护区发生火灾时,与系统配套的火灾报警和灭火控制器会发出指令,打开该保护区对应的启动瓶电磁驱动器,释放启动瓶中的气体,启动启动器。气体打开保护区的选择阀,然后通过驱动气体单向阀打开相应数量的灭火剂储存容器阀门,使灭火剂通过高压软管,液体单向阀、集流管、连接管、集流管、打开的选择阀和灭火剂输送管道输送到消防区。
When a fire occurs in any protection zone, the fire alarm and fire extinguishing controller matched with the system will send a command to open the electromagnetic driver of the starting bottle corresponding to the protection zone, release the gas in the starting bottle and start the starter. The gas first opens the selector valve in the protection area, and then opens the corresponding number of fire extinguishing agent storage container valves by driving the gas check valve, so that the fire extinguishing agent is transported to the fire area through the high-pressure hose, liquid check valve, collecting pipe, connecting pipe, collecting pipe, open selector valve and fire extinguishing agent transmission pipeline.
这一动作由启动管路上的驱动气体单向阀和收集管上的选择阀完成。驱动气体单向阀限制启动气体只流向设定的选择阀,打开设定数量的灭火剂储瓶,流向设定的保护区,从而完成大保护区的设定使用。瓶子数量和保护更多的区域组合分配。
This action is completed by the drive gas check valve on the starting pipeline and the selector valve on the collection pipe. The driving gas check valve restricts the starting gas to flow only to the set selection valve, opens the set number of fire extinguishing agent storage bottles, and flows to the set protection area, so as to complete the setting and use of the large protection area. The number of bottles and the protection of more areas are allocated in combination.
川消
川消无管网七氟丙烷灭火系统
Heptafluoropropane fire extinguishing system without pipe network
无管灭火系统又称预制式灭火系统,是预先设计并装配有灭火剂储存装置和喷淋组件的灭火系统。无管灭火系统可分为柜式灭火装置和悬挂式灭火装置。
Tubeless fire extinguishing system, also known as prefabricated fire extinguishing system, is a fire extinguishing system pre designed and equipped with extinguishing agent storage devices and sprinkler components. The tubeless fire extinguishing system can be divided into cabinet type fire extinguishing device and hanging type fire extinguishing device.
1、柜式灭火装置
1. Cabinet type fire extinguishing device
柜式七氟丙烷灭火装置由灭火剂瓶组、电磁驱动装置、金属软管、信号反馈装置、喷嘴、柜体组成。设备设置在保护区内。发生火灾时,将灭火剂直接喷入保护区。灭火剂无管道损失,灭火速度更快,效率更高。该设备有自动和手动两种启动方式。
The cabinet heptafluoropropane fire extinguishing device is composed of fire extinguishing agent bottle group, electromagnetic drive device, metal hose, signal feedback device, nozzle and cabinet. The equipment is set in the protected area. In case of fire, spray the extinguishing agent directly into the protection area. The fire extinguishing agent has no pipeline loss, so the fire extinguishing speed is faster and the efficiency is higher. The device can be started automatically or manually.
根据柜内钢瓶数量,柜式灭火装置分为单瓶组柜式灭火器和双瓶组柜式灭火器。
According to the number of steel cylinders in the cabinet, cabinet fire extinguishers are divided into single cylinder group cabinet fire extinguishers and double cylinder group cabinet fire extinguishers.
2、悬挂式灭火装置
2. Hanging fire extinguishing device
按启动方式,悬挂式灭火装置可分为电磁式和温敏式悬挂式灭火装置。
According to the starting mode, the hanging fire extinguishing devices can be divided into electromagnetic and temperature sensitive hanging fire extinguishing devices.
七氟丙烷灭火系统按是否有管网分类讲述内容就到这里了,如果您想更好的使用就要提前了解好这些设备的信息,以免到时候使用期发生不好的意外,可以关注我们网站http://www.cx-fire.com随时了解新资讯!
That's all for the heptafluoropropane fire extinguishing system according to whether there is a pipe network. If you want to use it better, you should know the information of these devices in advance to avoid bad accidents during the service life. You can follow our website http://www.cx-fire.com Keep abreast of new information!
