低倍数泡沫灭火系统的内外浮顶指代什么？实际上这个操作在使用中还是很重要的，下面川消小编就来为您讲讲吧。

What does the internal and external floating roof of low expansion foam fire extinguishing system mean? In fact, this operation is very important in use. Let's talk about it for you.

低倍数泡沫灭火系统--外浮顶

Low expansion foam fire extinguishing system -- external floating roof

1、飞水溶性液体的泡沫混合液提供强度不应小于12.5L/(min.m)，连续供给不应小于30min2、外浮顶檐口设计①泡沫堰板高出密封0.2m。设在挡雨板下泡沫堰板不应小于0.3m。

1. The supply strength of foam mixed liquid of water-soluble liquid shall not be less than 12.5l / (min.m), and the continuous supply shall not be less than 30min2. External floating roof cornice design: ① the foam weir plate shall be 0.2m higher than the seal. The foam weir plate set under the rain shield shall not be less than 0.3m.

②泡沫喷射口泡沫堰板与管壁有不应小于0.6m间距。喷射口在浮顶上时，泡沫堰板与管壁不宜小于0.6间距。

② The spacing between the foam weir plate at the foam injection port and the pipe wall shall not be less than 0.6m. When the injection port is on the floating roof, the spacing between the foam weir plate and the pipe wall should not be less than 0.6.

低倍数泡沫灭火系统--内浮顶

Low expansion foam fire extinguishing system -- inner floating roof

1、泡沫堰板与管壁间距不应小于0.55m，高度不应小于0.5m2、单个泡沫产生器保护周长不应大于24m3、非水溶液体的泡沫混合液供给强度不应小于12.5L(min.m)，连续供给不应小于30min。

1. The distance between the foam weir plate and the pipe wall shall not be less than 0.55M, the height shall not be less than 0.5m2, the protection perimeter of a single foam generator shall not be greater than 24m3, the supply intensity of the foam mixed liquid of non water soluble liquid shall not be less than 12.5l (min.m), and the continuous supply shall not be less than 30min.

低倍数泡沫灭火系统--固定顶设施要求

Low expansion foam fire extinguishing system -- Requirements for fixed roof facilities

1、非水溶性泡沫液储罐液下半液下喷射，起泡沫混合液供给强度不应小于5L/(min.m)，连续供给不应小于40min。

1. The water-insoluble foam liquid is sprayed under the liquid and half liquid in the storage tank. The supply intensity of foam mixed liquid shall not be less than 5L / (min.m), and the continuous supply shall not be less than 40min.

2、泡沫进入甲乙液体的速度不应大于3m/s；泡沫进入丙类液体速度不应大于6m/s，对于水溶性液体储罐来说，应设置泡沫缓冲装置。

2. The velocity of foam entering the liquid of Party A and Party B shall not be greater than 3m / S; The velocity of foam entering class C liquid shall not be greater than 6m / s. for water-soluble liquid storage tanks, foam buffer devices shall be provided.

3、每个泡沫产生器应用独立的混合液管道引致防火堤外。

3. Each foam generator shall be led out of the fire dike by an independent mixed liquid pipeline.

4、连接泡沫产生器的泡沫混合液立管应用关卡固定在管壁上，关卡间距不宜大于3m。

4. The foam mixed liquid riser connected to the foam generator shall be fixed on the pipe wall with gates, and the distance between gates shall not be greater than 3m.

5、防护堤外泡沫混合液或泡沫管道的设置要求：

5. Requirements for setting of foam mixed liquid or foam pipeline outside the protective Embankment:

①固定式液上喷射：每个泡沫产生器应在防护堤外独立设置控制阀。

① Fixed liquid jet: each foam generator shall be provided with an independent control valve outside the protective dike.

②半固定液上喷射：每个泡沫产生器应在防火堤距地0.7m设置带有门馆的管牙接口。

② Spray on semi fixed liquid: each foam generator shall be provided with a pipe thread interface with a door hall 0.7m above the ground.

③泡沫混合液管道或泡沫管道上应设置放空阀且其管道应有2%的坡度破相放空阀。

③ Vent valve shall be set on foam mixed liquid pipeline or foam pipeline, and the pipeline shall be provided with 2% gradient phase break vent valve.

低倍数泡沫灭火系统的内外浮顶的相关内容在以上就已经讲解完毕了，您可以结合资料来进行充分的了解，更多相关内容就来我们网站http://www.cx-fire.com咨询吧。

The related contents of the internal and external floating roofs of the low expansion foam fire extinguishing system have been explained above. You can fully understand them in combination with the information. For more related contents, please visit our website http://www.cx-fire.com Consult.
