二氧化碳灭火系统由于其来源广、便宜、灭火性能稳定、绝缘性好、技术相对成熟等特点，在工程实践中得到了越来越广泛的应用。那么你知道高压二氧化碳灭火系统的储存装置如何吗？下面川消小编为您分析。

Carbon dioxide fire extinguishing system has been widely used in engineering practice due to its wide source, low price, stable fire extinguishing performance, good insulation, relatively mature technology and other characteristics. Do you know how the storage device of high-pressure carbon dioxide fire extinguishing system is? Now let's analyze it for you.

二氧化碳灭火系统主要用于民用建筑中的大型、中型电子计算机房、通信机房、图书馆、档案库、贵重设备室、自备发电机房和工业建筑中的大型印刷机、纺织机、轧机、干燥机、液压机等机械设备和重要仓库的灭火保护。

The carbon dioxide fire extinguishing system is mainly used for the fire protection of large and medium-sized electronic computer rooms, communication rooms, libraries, archives, valuable equipment rooms, self provided generator rooms, large printing machines, textile machines, rolling mills, dryers, hydraulic presses and other mechanical equipment and important warehouses in civil buildings.

但是，经常有人停留或工作的地方，不适合设置系统。根据灭火剂的储存方式，二氧化碳灭火系统可分为高压二氧化碳灭火系统(以下简称高压系统)和低压二氧化碳灭火系统(以下简称低压系统)。

However, the place where people often stay or work is not suitable for setting the system. According to the storage mode of fire extinguishing agent, carbon dioxide fire extinguishing system can be divided into high-pressure carbon dioxide fire extinguishing system (hereinafter referred to as high-pressure system) and low-pressure carbon dioxide fire extinguishing system (hereinafter referred to as low-pressure system).

高压系统是指常温下储存灭火剂的系统，低压系统是指在-18~-20低温下储存灭火剂的系统。

High pressure system refers to the system that stores fire extinguishing agent at normal temperature, and low pressure system refers to the system that stores fire extinguishing agent at - 18~- 20 low temperature.

高压系统的储存装置由储存容器、容器阀、单向阀和集流管等组成,而低压系统的储存装置由储存容器、容器阀、泄压装置、压力表、压力报警装置和制冷装置等组成。

The storage device of high-pressure system is composed of storage container, container valve, one-way valve and collecting pipe, while the storage device of low-pressure system is composed of storage container, container valve, safety relief device, pressure gauge, pressure alarm device and refrigeration device.

高压系统的储存容器采用的是钢瓶瓶组,钢瓶的规格一般为70L或90L,设计工作压力不应小于15MPa,充装密度0.67kg/L。由于高压系统每个钢瓶内充装的灭火剂量较少,当系统中二氧化碳储量较大时,所需钢瓶数量较多,设备间占地面积大。

The storage container of the high-pressure system is a steel cylinder group. The specification of the steel cylinder is generally 70L or 90L, the design working pressure should not be less than 15MPa, and the filling density is 0.67kg/L. As the fire extinguishing dose in each cylinder of the high-pressure system is small, when the carbon dioxide storage in the system is large, more cylinders are needed and the equipment room occupies a large area.

高压二氧化碳灭火系统的储存装置相关事项内容如上所述，当然仅供参考，具体的使用还是要根据您的实际决定，相关的注意细节您可以来我们网站http://www.cx-fire.com进行咨询！

The contents of the storage device of the high-pressure carbon dioxide fire extinguishing system are described above, which is for reference only. The specific use should be determined according to your actual situation. You can visit our website for details http://www.cx-fire.com Consult!
