自动跟踪定位射流灭火系统可用于扑救民用建筑和丙类生产车间、丙类库房中，下面川消小编来讲讲该设备的适用范围和不适用范围，以及它的设计参数如何。

The automatic tracking and positioning jet fire extinguishing system can be used to put out fire in civil buildings, Class C production workshops and Class C warehouses. Next, the small editor of Sichuan Fire Fighting will talk about the scope of application and inapplicability of the equipment, as well as its design parameters.

1.火灾类别为A类的下列场所：

1. The following places with fire category A:

1）净空高度大于12m的高大空间场所。

1) Tall space with clearance height greater than 12m.

2）净空高度大于8m且不大于12m，难以设置自动喷水灭火系统的高大空间场所。

2) The headroom is more than 8 m and not more than 12 m, and it is difficult to set up automatic sprinkler system in large space.

2.自动跟踪定位射流灭火系统不应用于下列场所：

2. The automatic tracking and positioning jet fire extinguishing system shall not be used in the following places:

1）经常有明火作业。

1) There is often open fire operation.

2）不适宜用水保护。

2) Not suitable for water protection.

3）存在明显遮挡。

3) Obvious occlusion exists.

4）火灾水平蔓延速度快。

4) The horizontal spread of fire is fast.

5）高架仓库的货架区域。

5) Shelf area of elevated warehouse.

6）火灾危险等级为现行标准《自动喷水灭火系统设计规范》GB50084规定的严重危险级。

6) The fire hazard level is the serious hazard level specified in the current national standard Code for Design of Automatic Sprinkler Systems (GB50084).

二、设计参数：

2、 Design parameters:

1.自动消防炮灭火系统和喷射型自动射流灭火系统应保证少2台灭火装置的射流能到达被保护区域的任一部位。

1. The automatic fire monitor fire extinguishing system and the jet automatic jet fire extinguishing system shall ensure that the jet of at least two fire extinguishing devices can reach any part of the protected area.

2.自动消防炮灭火系统用于扑救民用建筑内火灾时，单台炮的流量不应小于20L/s；用于扑救工业建筑内火灾时，单台炮的流量不应小于30L/s。

2. When the automatic fire monitor extinguishing system is used to put out fires in civil buildings, the flow of a single monitor shall not be less than 20L/s; When used to put out fires in industrial buildings, the flow of a single gun shall not be less than 30L/s.

3.喷射型自动射流灭火系统用于扑救轻危险级场所火灾时，单台灭火装置的流量不应小于5L/s；用于扑救中危险级场所火灾时，单台灭火装置的流量不应小于10L/s。

3. When the jet automatic jet fire extinguishing system is used to put out the fire in the light hazard area, the flow of a single fire extinguishing device shall not be less than 5L/s; When it is used to put out the fire in the medium and dangerous places, the flow of a single fire extinguishing device shall not be less than 10L/s.

4.自动消防炮灭火系统和喷射型自动射流灭火系统灭火装置的设计同时开启数量应按2台确定。

4. The number of automatic fire monitor fire extinguishing system and spray automatic jet fire extinguishing system fire extinguishing devices designed to be opened at the same time shall be determined by 2 sets.

5.喷洒型自动射流灭火系统的灭火装置布置应能使射流完全覆盖被保护场所及被保护物。系统的设计参数不应低于下表的规定。

5. The arrangement of the fire extinguishing device of the spray type automatic jet fire extinguishing system shall make the jet completely cover the protected place and the protected object. The design parameters of the system shall not be lower than those specified in the following table.

6.喷洒型自动射流灭火系统灭火装置的设计同时开启数量，应按保护场所内任何一点着火时，可能开启射流的灭火装置的大数量确定，且应符合下表的规定。

6. The number of fire extinguishing devices designed to be opened at the same time for the spray type automatic jet fire extinguishing system shall be determined according to the large number of fire extinguishing devices that may open the jet when any point in the protected area catches fire, and shall comply with the provisions of the following table.

7.自动跟踪定位射流灭火系统的设计持续喷水时间应不小于1h。

7. The design duration of automatic tracking and positioning jet fire extinguishing system shall not be less than 1h.

自动跟踪定位射流灭火系统的范围与设计相关内容就是以上了，希望您能够有所了解，更好的使用，还有什么疑惑或者需求就来我们网站http://www.cx-fire.com咨询吧！

The scope and design of the automatic tracking and positioning jet fire extinguishing system are the above. I hope you can understand and use it better. If you have any doubts or needs, please come to our website http://www.cx-fire.com Ask!
