川消讲解五种消防气体灭火系统
来源：http://www.cx-fire.com/ 日期：2023-03-01
消防气体灭火系统是灭火剂以气体或液体状态存贮于压力容器内，灭火时以气体（包括蒸汽、气雾）状态喷射作为灭火介质的灭火系统。消防气体灭火系统根据灭火剂类型的不同而分为很多种，那么常见的消防气体灭火系统有哪些呢？下面
川消小编为您讲解：
Fire gas fire extinguishing system is a fire extinguishing system in which the fire extinguishing agent is stored in the pressure vessel in the state of gas or liquid, and the fire extinguishing agent is sprayed in the state of gas (including steam and mist) as the fire extinguishing medium. Fire gas extinguishing systems are divided into many types according to different types of extinguishing agents. What are the common fire gas extinguishing systems? Next, Sichuan Xiaobian will explain to you:
一、七氟丙烷气体灭火系统
1、 Heptafluoropropane gas fire extinguishing system
七氟丙烷气体灭火系统对大气臭氧层的耗损潜能值（ODP）为零，是目前替代卤代烷1211、1301气体灭火系统理想的灭火系统。七氟丙烷不含固体粉尘、油渍，是液态储存气态释放，喷放后可自然排出或由通风系统迅速排出，现场无残留物对保护对象无二次破坏。
The ODP of heptafluoropropane gas fire extinguishing system to the atmospheric ozone layer is zero, and it is an ideal fire extinguishing system to replace the halogenated alkane 1211 and 1301 gas fire extinguishing system at present. Heptafluoropropane does not contain solid dust and oil stains. It is released in liquid storage and gas state. It can be discharged naturally or quickly by the ventilation system after spraying. There is no residue on the site and no secondary damage to the protected object.
七氟丙烷气体灭火系统的喷射时间很短，大大减少了火灾时设备的损坏度，为业主减少损失。灭火操作简单可靠:具有自动、手动和机械三种启动方式，确保了任何情况下均可灭火。广泛应用于机房、配电房、档案室、贵重的工业设备、图书馆等防护区的消防保护，能适应经常有人工作的防护区。
The spraying time of heptafluoropropane gas fire extinguishing system is very short, which greatly reduces the damage degree of equipment in case of fire and reduces the loss for the owner. The fire extinguishing operation is simple and reliable: it has three starting modes: automatic, manual and mechanical, ensuring that the fire can be extinguished under any circumstances. It is widely used for fire protection in key protection areas such as computer rooms, power distribution rooms, archives, valuable industrial equipment, libraries, etc., and can adapt to protection areas where people often work.
二、高压二氧化碳气体灭火系统
2、 High-pressure carbon dioxide gas fire extinguishing system
高压二氧化碳气体灭火系统灭火剂为100%二氧化碳气体，二氧化碳灭火剂来源广泛、低廉、电绝缘性高、清洁无残留物、长期贮存不变质，不会损坏设备，灭火时不污染火场环境，灭火后很快散逸、不留痕迹。高压二氧化碳气体灭火系统广泛应用于电厂、电站、轧机、印刷机、浸渍油槽、造漆、喷涂间、制药等易发生火灾的防护区的消防保护。
The fire extinguishing agent of the high-pressure carbon dioxide fire extinguishing system is 100% carbon dioxide gas. The carbon dioxide fire extinguishing agent has a wide range of sources, low price, high electrical insulation, clean and no residue, long-term storage without deterioration, and will not damage the equipment. It will not pollute the fire site environment during fire extinguishing, and will quickly disperse without leaving traces after fire extinguishing. High-pressure carbon dioxide gas fire extinguishing system is widely used for fire protection in key protection areas prone to fire, such as power plants, power stations, rolling mills, printing presses, impregnating oil tanks, paint making, spraying rooms, pharmaceuticals, etc.
三、火探管气体灭火系统
3、 Gas fire extinguishing system of fire detection tube
火探管气体灭火系统是是一套简单、低成本且高度可靠的独立自动探火气体灭火系统。火探管气体灭火系统采用柔性可弯曲的火探管作为火灾的探测报警部件.
The fire detection gas extinguishing system is a simple, low-cost and highly reliable independent automatic fire detection gas extinguishing system. The fire detection tube gas fire extinguishing system uses flexible and flexible fire detection tube as the fire detection and alarm component
火探管气体灭火系统无需任何电源，无需专门的烟、温感探测器，无需复杂的设备及管线，利用自身储压，能快速、准确、有效地探测及扑灭火源，集报警和灭火于一体，将火患扑灭在初阶段。
The fire detection tube gas fire extinguishing system does not need any power supply, special smoke and temperature detectors, and complex equipment and pipelines. It can quickly, accurately and effectively detect and extinguish the fire source by using its own pressure storage. It integrates alarm and fire extinguishing to put out the fire at the initial stage.
四、IG541混合气体灭火系统
4、 IG541 mixed gas fire extinguishing system
IG541混合气体灭火系统其灭火剂是由氮气、氩气和二氧化碳气体按一定的比例混合而成的气体，这些气体都是在大气层中自然存在的，对大气臭氧层没有损耗，也不会对地球的“温室效应”产生影响.
The fire extinguishing agent of IG541 mixed gas fire extinguishing system is a mixture of nitrogen, argon and carbon dioxide in a certain proportion. These gases are naturally present in the atmosphere, which does not damage the ozone layer of the atmosphere and will not affect the "greenhouse effect" of the earth
G541混合气体灭火系统主要适用于电子计算机房、通讯机房、配电房、油浸变压器、自备发电机房、图书馆、档案室、博物馆及票据、文物资料库等经常有人、工作的场所。
G541 mixed gas fire extinguishing system is mainly applicable to electronic computer room, communication room, power distribution room, oil-immersed transformer, self-contained generator room, library, archives, museum, bills, cultural relics database and other places where people often work.
五、热气溶胶灭火系统
5、 Hot aerosol fire extinguishing system
热气溶胶灭火系统是一种新型灭火剂，其灭火剂是由一种由氧化剂、还原剂、燃烧速度控制剂和粘合剂组成的固体混合物。
Hot aerosol fire extinguishing system is a new type of fire extinguishing agent. Its fire extinguishing agent is a solid mixture composed of oxidant, reducing agent, combustion rate control agent and adhesive.
热气溶胶灭火系统是以固态常温常压储存，不存在泄漏问题，维护方便；属于无管网灭火系统，安装灵活，不需要布置管道，工程造价相对较低。
The hot aerosol fire extinguishing system is stored in solid state at normal temperature and pressure, without leakage, and is easy to maintain; It belongs to the non-pipe network fire extinguishing system, which is flexible in installation, does not need to arrange pipes, and the project cost is relatively low.
热气溶胶灭火系统按灭火剂类型可分为K型、S型两种。按灭火装置喷口温度高低可分为限温型和非限温型。用于扑救电器火灾、固体表面火灾、液体火灾。
The hot aerosol fire extinguishing system can be divided into K type and S type according to the type of fire extinguishing agent. According to the nozzle temperature of the fire extinguishing device, it can be divided into temperature-limited type and non-temperature-limited type. It is used to put out electrical fire, solid surface fire and liquid fire.
The introduction of five kinds of fire gas extinguishing systems is over. Is it helpful to you? If you need fire protection products or systems, please come to our website http://www.cx-fire.com Leave a message for consultation!
