自动消防炮灭火装置是消防炮的一种。消防炮系指连续喷射时水、泡沫混合液流量大于16L/s或干粉平均喷射速率大于8kg/s，脉冲喷射时单发喷射水、泡沫混合液量不低于8L的喷射灭火剂的装置。

Automatic fire monitor fire extinguishing device is a kind of fire monitor. The fire monitor refers to a device that sprays fire extinguishing agent with the flow of water and foam mixture greater than 16l/s or the average spray rate of dry powder greater than 8kg/s during continuous spraying, and the volume of water and foam mixture per shot is not less than 8L during pulse spraying.

消防炮按喷射介质可分为消防水炮、消防泡沫炮和消防干粉炮；按驱动方式可分为手动消防炮、电动消防炮、液动消防炮和气动消防炮；按控制方式可分为远控消防炮和非远控消防炮；按使用功能可分为单用消防炮、两用消防炮和组合消防炮；按安装方式可分为移动式消防炮和固定式消防炮。

Fire monitor can be divided into fire water monitor, fire foam monitor and fire dry powder monitor according to the spraying medium; According to the driving mode, it can be divided into manual fire monitor, electric fire monitor, hydraulic fire monitor and pneumatic fire monitor; According to the control mode, it can be divided into remote control fire monitor and non remote control fire monitor; According to the use function, it can be divided into single fire monitor, dual-purpose fire monitor and combined fire monitor; According to the installation method, it can be divided into mobile fire monitor and fixed fire monitor.

其中，移动式消防炮按移动方式又可分为便携移动式消防炮、手抬移动式消防炮和拖车移动式消防炮。

Among them, the mobile fire monitor can be divided into portable mobile fire monitor, hand lift mobile fire monitor and trailer mobile fire monitor according to the moving mode.

自动消防炮灭火装置和喷射型自动射流灭火装置由探测部分、控制部分、自动消防炮部分和联动部分组成。喷洒型自动射流灭火装置由探测部分和洒水部分组成，其探测部分也可以独立设置，但一套探测部分不宜联动4个洒水部分。所选择的探测部分与洒水部分应尽量对应。

Automatic fire monitor fire extinguishing device and jet type automatic jet fire extinguishing device are composed of detection part, control part, automatic fire monitor part and linkage part. The sprinkler type automatic jet fire extinguishing device is composed of a detection part and a sprinkler part. The detection part can also be set independently, but a set of detection parts should not be linked with four sprinkler parts. The selected detection part shall correspond to the watering part as much as possible.

川消灭火装置的布置应根据设置场所的净空高度、平面布局等建筑条件合理确定。灭火装置应满足相应使用环境和介质的防腐蚀要求，自动消防炮和喷射型自动射流灭火装置的俯仰和水平回转角度应满足使用要求，自动消防炮应具有直流-喷雾的转换功能。灭火装置与端墙之间的距离不宜超过灭火装置同向布置间距的一半。

The layout of Sichuan fire extinguishing device shall be reasonably determined according to the clearance height, plane layout and other building conditions of the setting place. The fire extinguishing device shall meet the anti-corrosion requirements of the corresponding use environment and medium, the pitch and horizontal rotation angles of the automatic fire monitor and the jet type automatic jet fire extinguishing device shall meet the use requirements, and the automatic fire monitor shall have the DC spray conversion function. The distance between the fire extinguishing device and the end wall should not exceed half of the same direction layout spacing of the fire extinguishing device.

灭火装置安装的设计应符合规定：安装位置应满足灭火装置正常使用和维护的要求。定支架或安装平台应能满足灭火装置的喷射、喷洒反作用力要求，且结构设计应能满足灭火装置正常使用的要求。

The design of fire extinguishing device installation shall comply with the regulations: the installation position shall meet the requirements of normal use and maintenance of fire extinguishing device. The fixed support or installation platform shall meet the requirements of the spraying and spraying reaction force of the fire extinguishing device, and the structural design shall meet the requirements of the normal use of the fire extinguishing device.

在选择灭火装置的时候，可以根据场景的不同，选择不同参数的灭火装置相关设备，让自己的需求更加满意。更多内容就来我们网站www.cx-fire.com进行咨询。

When selecting fire extinguishing devices, you can select relevant equipment of fire extinguishing devices with different parameters according to different scenes to make your needs more satisfied. For more information, please visit our website at www.cx-fire.com Com.
